DF Series
Connect with an Expert
The Rosedale® DF Series Filter Bags have up to 4X the dirt holding capacity of standard bags at the equivalent micron ratings. Rosedale® DF Series bags are easy to install and remove, and require less room in storage and disposal. Because the dirt is caught inside the bag, contaminant wash off downstream associated with exterior surface loading filter cartridges is avoided. Rosedale® DF Series bags produce excellent results when used as a pre-filter for membrane filtration and other fine filters.
SPECIFICATIONS
• Available in #1 and #2 sizes
• Removal Ratings (microns): 1, 5, 10, 25, 50, 100, 200 Nominal
• Maximum Operating Temperature: Polypropylene 180°F / 82°C Polyester 300°F / 140°C
• Maximum Differential Pressure: 35 psid @ 68°F (1.03 bar @ 20°C)
• Recommended Change-Out Differential Pressure: 20 psid @ 68°F (.83 bar @ 20°C)
• Maximum Flow Rate: 75 gpm (#1 size) or 150 gpm (#2 size)
• Recommended Flow Rate: 40 gpm (#1 size) or 80 gpm (#2 size)
• 60% more media compared to standard bags (reduced hold-up volume which minimizes product waste and waste management fees)
• Rosedale® DF Series bags lasts up to 4X longer than standard bags
SPECIFICATIONS
• Available in #1 and #2 sizes
• Removal Ratings (microns): 1, 5, 10, 25, 50, 100, 200 Nominal
• Maximum Operating Temperature: Polypropylene 180°F / 82°C Polyester 300°F / 140°C
• Maximum Differential Pressure: 35 psid @ 68°F (1.03 bar @ 20°C)
• Recommended Change-Out Differential Pressure: 20 psid @ 68°F (.83 bar @ 20°C)
• Maximum Flow Rate: 75 gpm (#1 size) or 150 gpm (#2 size)
• Recommended Flow Rate: 40 gpm (#1 size) or 80 gpm (#2 size)
• 60% more media compared to standard bags (reduced hold-up volume which minimizes product waste and waste management fees)
• Rosedale® DF Series bags lasts up to 4X longer than standard bags
The Rosedale® DF Series Filter Bags have up to 4X the dirt holding capacity of standard bags at the equivalent micron ratings. Rosedale® DF Series bags are easy to install and remove, and require less room in storage and disposal. Because the dirt is caught inside the bag, contaminant wash off downstream associated with exterior surface loading filter cartridges is avoided. Rosedale® DF Series bags produce excellent results when used as a pre-filter for membrane filtration and other fine filters.
SPECIFICATIONS
• Available in #1 and #2 sizes
• Removal Ratings (microns): 1, 5, 10, 25, 50, 100, 200 Nominal
• Maximum Operating Temperature: Polypropylene 180°F / 82°C Polyester 300°F / 140°C
• Maximum Differential Pressure: 35 psid @ 68°F (1.03 bar @ 20°C)
• Recommended Change-Out Differential Pressure: 20 psid @ 68°F (.83 bar @ 20°C)
• Maximum Flow Rate: 75 gpm (#1 size) or 150 gpm (#2 size)
• Recommended Flow Rate: 40 gpm (#1 size) or 80 gpm (#2 size)
• 60% more media compared to standard bags (reduced hold-up volume which minimizes product waste and waste management fees)
• Rosedale® DF Series bags lasts up to 4X longer than standard bags
SPECIFICATIONS
• Available in #1 and #2 sizes
• Removal Ratings (microns): 1, 5, 10, 25, 50, 100, 200 Nominal
• Maximum Operating Temperature: Polypropylene 180°F / 82°C Polyester 300°F / 140°C
• Maximum Differential Pressure: 35 psid @ 68°F (1.03 bar @ 20°C)
• Recommended Change-Out Differential Pressure: 20 psid @ 68°F (.83 bar @ 20°C)
• Maximum Flow Rate: 75 gpm (#1 size) or 150 gpm (#2 size)
• Recommended Flow Rate: 40 gpm (#1 size) or 80 gpm (#2 size)
• 60% more media compared to standard bags (reduced hold-up volume which minimizes product waste and waste management fees)
• Rosedale® DF Series bags lasts up to 4X longer than standard bags
