In Stock Model 4 Basket Strainers and Bag Filters


Specification PDF PDF
Click image to enlarge
Model 4 Basket Strainers and Bag Filters offer complete customization based on your application’s exact specifications. The Model 4 single bag filter housings can be used for 50 gallon per minute flow rates and are available in two bag sizes and pressure ratings. The Model 4 Strainers are available with 304 or 316 stainless steel, and carbon steel vessels.
  • Model 4-6 uses trade size 3 filter bags
  • Model 4-12 uses trade size 4 filter bags


Contact us for more information regarding our Model 4 Basket Strainers and Model 4 Bag Strainers or call us at 800-821-5373 and we will gladly answer your filtration system housing questions. Rosedale Products is your trusted source for in stock and custom high quality filtration housing systems.
Model 4 Basket Strainers and Bag Filters offer complete customization based on your application’s exact specifications. The Model 4 single bag filter housings can be used for 50 gallon per minute flow rates and are available in two bag sizes and pressure ratings. The Model 4 Strainers are available with 304 or 316 stainless steel, and carbon steel vessels.
  • Model 4-6 uses trade size 3 filter bags
  • Model 4-12 uses trade size 4 filter bags


Contact us for more information regarding our Model 4 Basket Strainers and Model 4 Bag Strainers or call us at 800-821-5373 and we will gladly answer your filtration system housing questions. Rosedale Products is your trusted source for in stock and custom high quality filtration housing systems.

Model 4 Filter Housing Features

Single bag filter vessels provide technologically advanced filtration capabilities for industrial water, coolant, chemicals, and fluid treatment applications. Whether the application requires the filtration of city water, waste water, food, beverages, or machine tool coolants, single basket strainers provide state-of-the-art filtration in various sizes and flow rates. Beneficial features include:
  • Maximum flow rate of 50 GPM
  • Carbon steel, or stainless steel (304 or 316) construction for housings
  • Model 4-6 uses trade size 3 filter bags
  • Model 4-12 uses trade size 4 filter bags
  • Clamp or eye-bolt lid closure
  • Maximum 2" NPT connections
  • ASME Code option available

Model 4 Basket Strainer and Bag Filters

Need a Filter Bag?

Rosedale Products has a wide selection of filter bag in stock. Our selection includes but is not limited to:

  • Standard Filter Bags
  • High Efficiency Filter Bags
  • High Temperature Filter Bags
  • High Life Filter Bags
  • OA & OS Series Filter Bags
  • Graded Density Filter Bags
View Bags Here Filter Bags
Rosedale Products’ Model 4 Basket Strainers and Model 4 Bag Filters are available in two sizes and pressure ratings. Additionally, the covers can be easily removed without special tools, and the basket or bag is easily cleaned or replaced. Model 4 Basket Strainer and Bag Filter features include:
  • Low pressure drops
  • Covers are O-ring sealed
  • All vessels are electropolished to resist adhesion of dirt and scale
  • Adjustable-height legs, optional
  • O-ring seals: Buna N, EPR, Fluoroelastomer, PTFE
  • ASME code stamp available on select models
  • Liquid displacers for easier servicing
  • Two pressure ratings: 200 psi (with clamp cover) and 500 psi (with eyenut cover)
  • Pipe sizes 1 thru 2-inch, NPT
  • Two basket depths: 6, or 12 inches (nominal)
  • Accepts trade size #3 or #4 filter bags

Model 4 Basket Strainer and Bag Filter Customization Options

At Rosedale Products, we understand that sometimes the best path to success is through customization. Our technologically advanced Model 4 Basket Strainer and Bag Filter Part Builders offers unique customization to meet your exact application requirements. Custom options include:

Not Sure What You Need?

Check out our application worksheet for some general rules of thumb or tell us what specifications you need and we'll help you find the filter housing to match!

View Worksheet worksheet
  • Different outlet connections
  • Higher pressure ratings
  • Extra-length legs
  • Heat jacketing
  • Epoxy coating
  • Displacers
  • Magnets
  • Duplex units available

Contact Rosedale Products for Liquid Model 4 Bag Filters Today

Contact us for more information regarding our Model 4, 50 gallon per minute flow rate single bag filter housing options, or request a quote for further pricing details today. Rosedale Products is your premier source for standard and custom Model 4 Basket Strainers and Bag Filters.
